Запчасти Komatsu PC200-6B КЛАПАН PPC(ДЛЯ ХОДА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
32
33
35
34
36
30
1
32
33
35
34
36
2
3
4
6
5
7
9
10
8
26
29
28
27
13
23
20
15
16
11
20
23
13
27
28
29
26
17
18
21
22
14
19
12
19
20
12
24
25
31
|1
702-16-01540
PILOT VALVE
1
BODY, VALVE
2
VALVE
3
702-16-51140
SHIM 0.30MM, 0.3MM
4
702-16-53420
SPRING
5
702-16-53140
RETAINER
6
702-16-54420
SPRING
7
702-16-53170
PISTON
8
702-16-51270
SEAL
9
07000-02020
O-RING
10
702-16-54170
COLLAR
11
702-16-54310
CASE
12
LEVER
13
SHAFT
14
PLATE
15
01010-80855
BOLT
16
01643-30823
WASHER
17
01010-80816
BOLT
18
702-16-54331
WASHER, 1.60MM, 1.6MM
19
04025-00432
PIN, SPRING
20
702-16-54430
BUSHING
21
702-16-54341
WASHER, 1.30MM, 1.3MM
22
702-16-54351
WASHER, 1.00MM, 1.0MM
23
702-16-54280
SEAL, DUST
24
702-16-54500
DAMPER ASS’Y
25
01252-30525
BOLT
26
702-16-54510
PLATE
27
04025-00420
PIN, SPRING
28
LEVER
29
01224-40612
SCREW
30
PLUG
31
PLUG
32
07040-11209
PLUG
33
07002-11223
O-RING
34
700-84-11730
BALL
35
702-16-55940
PLUG
36
702-16-55950
SEAT
