Запчасти Komatsu PC200-6B МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-8F-00110

TRAVEL MOTOR ASS’Y

1

708-8F-32110

SHAFT

2

708-8F-12151

BEARING

3

708-7L-12140

BEARING

4

708-7L-05010

SPACER KIT

|4

SPACER, 1.5MM

|4

SPACER, 1.6MM

|4

SPACER, 1.7MM

|4

SPACER, 1.8MM

|4

SPACER, 1.9MM

|4

SPACER, 2.0MM

5

706-7G-11290

SEAL, OIL

6

708-8F-12230

SPACER, 3.2MM

7

04065-07225

RING

8

BLOCK, CYLINDER

9

PLATE, VALVE

10

PIN

11

708-8F-33360

PIN

12

708-7L-13140

SEAT

13

708-8F-33150

SPRING

14

04065-04818

RING, SNAP

15

708-8F-33350

RETAINER, GUIDE

16

708-8F-33340

RETAINER, SHOE

17

708-8F-33310

PISTON SUB ASS’Y

18

708-8F-33410

CAM, ROCKER

19

708-8F-33710

BALL, RETAINER

20

708-8F-34141

PISTON

21

708-8F-34150

SPRING

22

708-8F-35110

PLATE

23

708-8F-35130

PLATE

24

708-8F-35120

DISC

25

708-8F-35140

PISTON, BRAKE

26

708-8F-35160

O-RING

27

708-8F-35170

RING, BACK-UP

28

708-8F-35180

O-RING

29

708-8F-35190

RING, BACK-UP

30

708-8F-35150

SPRING

31

04025-00324

PIN, SPRING
