Запчасти Komatsu PC200-6 МОТОР ПОВОРОТА(/)(ОПЦИОНН.) Y [SERVICE KOT]

|$1

706-75-01170

SWINGMOTORASS'Y

1

565-14-22440

O-RING

2

01252-61445

BOLT

3

706-75-43660

SHAFTDRIVE

4

706-75-42880

BEARING

5

706-75-43810

SPACER

6

706-75-11260

SPRING

7

706-75-11270

SEAL

8

706-76-40890

BEARING

9

706-75-05040

SPACER(KIT)

|$12

706-75-43440

SPACER

|$13

706-75-43450

SPACER

|$14

706-75-43460

SPACER

10

04064-04518

RINGSNAP

11

706-75-43410

SEAL,OIL

12

706-75-43720

SPACER

13

04065-06220

RING

14

706-75-43190

BLOCKCYLINDER

15

706-75-43741

PLATEVALVE

16

706-75-43750

RIN,DOWEL

17

706-75-43120

SHAFT,CENTER

18

706-75-43130

RING,CENTER

19

706-75-41110

SPRING

|$25

706-75-05020

RETAINERLIT

20

706-75-42260

RETAINER

21

706-75-42270

SCREW

22

706-75-43160

PISTONASS'Y

23

706-75-92130

PLATE

24

706-75-92340

PLATE

25

706-75-92350

DISK

26

706-75-92380

PISTONSUBBRAKE

27

706-75-92390

RINGBRAKE

28

07000-12145

O-RING

29

706-75-92310

O-RING

30

706-75-92170

SPRING
