Запчасти Komatsu PC200-6 ЦИЛИНДР КОВША(СПЕЦ-Я ДЛЯ РАЗРУШ. ЗДАНИЙ)(УДЛИНН. СИСТ. СМАЗКИ TYPR)(ОПЦИОНН.) Y [SERVICE KOT]

G1

205-63-X7290

BUCKETCYLINDERG

|$2

205-63-07290

CYLNDERASS'Y

1

205-63-74740

CYLINDER

2

20Y-70-21360

BUSHING

3

07145-00080

SEAL,DUST(KIT)

4

206-63-74720

ROD,PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL,DUST(KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-130104

RING,SNAP

9

195-63-94170

SEAL,DUST(KIT)

10

707-52-90680

BUSHING

11

707-51-90030

PACKING,ROD(KIT)

12

07000-15120

O-RING(KIT)

13

707-35-91320

RING,BACK-UP(KIT)

14

707-51-90630

RING,BUFFER(KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13471

PISTON

18

707-44-13180

RING,PISTON(KIT)

19

707-39-13110

RING,WEAR(KIT)

20

707-44-13911

RING

21

707-35-90940

RING,BACK-UP(KIT)

22

07000-15180

O-RING(KIT)

23

01310-01216

SCREW

24

07020-00000

FITTINGGREASE

25

07020-00900

FITTINGGREASE

26

206-63-74770

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING(KIT)

30

707-88-95980

BRACKET

31

707-88-96100

BAND

32

01010-81035

BOLT

33

01643-51032

WASHER

34

07282-02793

CLAMP

35

01010-81020

BOLT

36

01643-31032

WASHER
