Запчасти Komatsu PC200-6 ROTATION РУКОЯТЬ (.9M) (ВТОР. РУКОЯТЬ) (С ДОПОЛН. ГИДРОЛИНИЕЙ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$9

20Y-966-0011

ARM A,(2ND ARM)

|$10

20Y-966-0010

2ND ARM ASS'Y

1

SECOND ARM

1

ARM,2ND

2

21K-70-12170

BUSHING

3

205-70-72130

BUSHING

4

07020-00000

FITTING

5

20Y-966-1530

PLATE

6

01010-81235

BOLT

6

01010-51235

BOLT

7

01643-31232

WASHER

8

20Y-966-1510

COVER

9

20Y-966-1520

SEAL

10

01010-81220

BOLT

10

01010-51220

BOLT

11

01643-31232

WASHER

12

205-966-7111

CIRCLE

13

01011-82210

BOLT

14

703-09-33400

SWIVEL JOINT ASS'Y

14

703-09-00120

SWIVEL JOINT ASS'Y

14

703-09-33230

SWIVEL JOINT ASS'Y,(SEE FIG. Y1627-01A0)

14

703-09-33230

SWIVEL JOINT ASS'Y,(SEE FIG. Y1627-01A0)

15

20Y-966-2850

TUBE

16

20Y-966-2950

FLANGE

17

07000-13030

O-RING

18

01252-41020

BOLT

19

07372-21035

BOLT

20

01643-51032

WASHER

21

07000-13030

O-RING

22

07040-12412

PLUG

23

07002-02434

O-RING

24

07040-11409

PLUG

25

07002-11423

O-RING

26

114-62-23110

NIPPLE

27

07002-02434

O-RING

28

07103-20311

HOSE
