Запчасти Komatsu PC200-5C ГИДР. НАСОС. (9/) (СЕРВОКЛАПАН¤ ЗАДН.) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

G-1

20Y-60-X1261

PUMP GROUP

|$$2

====================

|$2

708-25-04051

PUMP ASS'Y

|$3

708-25-04014

PUMP ASS'Y

|$4

708-25-04013

PUMP ASS'Y

|$5

708-25-04012

PUMP ASS'Y

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6101 TO 6151.

|$7

708-25-04613

SERVO VALVE ASS'Y,REAR

|$8

708-25-04612

SERVO VALVE ASS'Y,REAR

|$$10

(708-25-04613,708-25-04521)

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6131 TO 6137.

|$11

708-25-16701

SERVO VALVE SUB A.,REAR

|$12

708-25-16700

SERVO VALVE SUB A.,REAR

|$13

708-23-00421

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-25110

SPRING

6

708-23-15160

PLUG

7

07000-02018

O-RING

8

708-25-15150

COVER

9

01580-10806

NUT

10

708-25-15320

BOLT

11

01602-20619

WASHER,SPRING

12

708-25-15171

PLUG

13

07002-02034

O-RING

14

07239-12009

NUT

15

07040-11007

PLUG

16

07002-01023

O-RING

17

708-25-15180

SLEEVE

18

708-25-15280

SPOOL

19

708-25-15310

SPRING

20

708-25-15330

SPACER

21

708-25-15430

PLUG

22

07000-02012

O-RING

23

708-25-15250

COVER

24

01580-10806

NUT

25

708-25-15320

BOLT

26

01602-20619

WASHER,SPRING

27

708-25-15260

PLUG

28

07002-00823

O-RING

29

708-25-15270

ARM

30

708-25-15360

PIN

31

708-25-15370

WASHER

32

708-25-15380

E-RING

33

708-25-15340

SCREW

34

708-23-15120

SEAT

35

708-25-25150

SPRING

35

708-25-55120

SPRING

|$$51

====================
