Запчасти Komatsu PC200-5C ГИДР. НАСОС. (8/) (СЕРВОКЛАПАН¤ ЗАДН.) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

G-1

20Y-60-X1261

PUMP GROUP

|$$2

====================

|$2

708-25-04051

PUMP ASS'Y

|$3

708-25-04014

PUMP ASS'Y

|$4

708-25-04013

PUMP ASS'Y

|$5

708-25-04012

PUMP ASS'Y

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6101 TO 6151.

|$7

708-25-04613

SERVO VALVE ASS'Y,REAR

|$8

708-25-04612

SERVO VALVE ASS'Y,REAR

|$$10

(708-25-04613,708-25-04521)

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6131 TO 6137.

1

708-25-16701

SERVO VALVE SUB A.,REAR

1

708-25-16700

SERVO VALVE SUB A.,REAR

2

708-25-04811

VALVE ASS'Y,CO AND NC

3

708-25-04911

VALVE ASS'Y,TVC

4

07000-02011

O-RING

5

07000-02018

O-RING

6

07000-11009

O-RING

7

708-25-19160

BOLT

8

01602-20825

WASHER,SPRING

9

708-25-18130

BOLT

10

01602-20825

WASHER,SPRING

11

720-68-11920

FILTER

12

708-25-19191

ORIFICE

13

07000-12010

O-RING

14

07000-11009

O-RING

15

720-68-11920

FILTER

16

708-25-19150

ORIFICE

17

07000-12010

O-RING

18

07000-03048

O-RING

19

08053-01512

CLIP

20

01010-30812

BOLT

21

01643-30823

WASHER
