Артикул
Название
Примечание
Количество
G-1
20Y-60-X1261
PUMP GROUP
|$$2
====================
|$2
708-25-04051
PUMP ASS'Y
|$3
708-25-04014
PUMP ASS'Y
|$4
708-25-04013
PUMP ASS'Y
|$5
708-25-04012
PUMP ASS'Y
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6101 TO 6151.
|$7
708-25-04521
SERVO VALVE ASS'Y,FRONT
|$8
708-25-04520
SERVO VALVE ASS'Y,FRONT
|$$10
(708-25-04521,708-25-04613)
|$$11
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6121 TO 6125.
|$11
708-25-04711
VALVE ASS'Y,CO AND NC
|$12
708-23-00430
BODY ASS'Y
1
BODY
2
EXPANDER
3
708-25-17460
PLUG
4
07000-02010
O-RING
5
708-25-17131
COVER
6
01580-10806
NUT
7
708-25-17141
SPOOL
8
708-25-17150
SLEEVE
9
708-25-17160
PISTON
10
708-25-17170
COVER
11
07000-02014
O-RING
12
708-25-17180
SEAT
13
708-25-17690
SPRING
14
708-25-17451
SLEEVE
15
07000-02012
O-RING
16
708-25-17220
PISTON
17
07000-12012
O-RING
18
07001-02012
RING,BACK-UP
19
708-25-17370
SEAT
20
708-25-17250
SPRING
21
708-25-17260
SEAT
22
708-23-17240
COVER
23
708-25-17380
PLUG
24
07000-02021
O-RING
25
708-23-17270
PISTON
26
708-25-15320
BOLT
27
01602-20619
WASHER,SPRING
28
01580-10806
NUT
29
708-25-15320
BOLT
30
01602-20619
WASHER,SPRING
31
07000-12021
O-RING
32
07001-02021
RING,BACK-UP
33
07040-11007
PLUG
34
07002-01023
O-RING
35
708-25-17430
SCREW
36
708-25-15340
SCREW
37
708-23-17290
COVER
38
07000-03028
O-RING
39
706-75-40310
BOLT
40
01602-20619
WASHER,SPRING
|$$54
====================
Выбрано товаров: 54
