Запчасти Komatsu PC200-5 ГУСЕНИЦЫ (БОЛОТН.) ХОДОВАЯ

Схема запчастей Komatsu PC200-5 - ГУСЕНИЦЫ (БОЛОТН.) ХОДОВАЯ
1
2
3
4
5
6
7
7
8
9
10
10
11

Артикул

Название

Примечание

Количество

|$1

20Y-32-01043

TRACK SHOE ASS'Y

1

20Y-32-11340

SHOE,TRACK

2

20Y-32-11230

BOLT,SHOE (KIT)

3

154-32-31220

NUT, SHOE (KIT)

|$5

20Y-32-00013

TRACK LINK ASS'Y

4

20Y-32-11123

LINK,TRACK, L.H.

5

20Y-32-11133

LINK,TRACK, R.H.

6

20Y-32-11140

BUSHING, REGULAR

7

20Y-32-11240

SEAL,DUST, REGULAR, W-TYPE

8

20Y-32-11150

PIN, REGULAR

9

20Y-32-11170

BUSHING, MASTER

10

20Y-32-11260

SEAL,DUST, MASTER, W-TYPE

11

20Y-32-11190

PIN, MASTER

1

20Y-32-05010

SHOE BOLT AND NUT K.

1

20Y-32-11230

BOLT,SHOE

2

154-32-31220

NUT, SHOE

6

20Y-98-09110

BUSHING, REGULAR

8

20Y-98-09010

PIN, REGULAR

9

20Y-98-09130

BUSHING, MASTER

11

20Y-98-09030

PIN, MASTER

6

20Y-98-09120

BUSHING, REGULAR

8

20Y-98-09020

PIN, REGULAR

9

20Y-98-09140

BUSHING, MASTER

11

20Y-98-09040

PIN, MASTER

Выбрано товаров: 24
