Запчасти Komatsu PC200-5 ЛЕВ. СТОЙКА СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА

1

20Y-43-16540

COVER, L.H. CONSOLE

1A

20Y-43-16550

BUTTON, L.H. CONSOLE ADJUSTMENT

1B

20Y-43-16580

TRAY, L.H. CONSOLE

|$3

20Y-43-16500

CASE ASSEMBLY, L.H

2

20Y-43-16520

CASE, L.H. STAND

3

20Y-43-16560

COVER, ARM REST

4

20Y-43-16570

REST, ARM L.H. STAND

5

01010-60850

BOLT

6

01010-60816

BOLT

7

01643-30823

WASHER

8

20Y-43-16530

BRACKET, L.H. CONSOLE

9

20Y-43-16510

RAIL, L.H. CONSOLE SLIDING

|$12

20Y-43-16380

CABLE

10

01580-10806

NUT

11

01643-30823

WASHER

12

20Y-43-16590

SCREW

13

01010-60820

BOLT

14

01580-10806

NUT

15

01643-70823

WASHER

16

20Y-43-16112

STAND, L.H. CONSOLE

17

01010-51225

BOLT

18

01643-31232

WASHER

19

205-43-72480

COVER

20

20Y-43-16121

COVER, L.H. STAND

21

01010-50820

BOLT

22

01643-30823

WASHER

1

20Y-43-16540

COVER, L.H. CONSOLE

1A

20Y-43-16550

BUTTON, L.H. CONSOLE ADJUSTMENT

1B

20Y-43-16580

TRAY, L.H. CONSOLE

|$3

20Y-43-16500

CASE ASSEMBLY, L.H

2

20Y-43-16520

CASE, L.H. STAND

3

20Y-43-16560

COVER, ARM REST

4

20Y-43-16570

REST, ARM L.H. STAND

5

01010-60850

BOLT

6

01010-60816

BOLT

7

01643-30823

WASHER

8

20Y-43-16530

BRACKET, L.H. CONSOLE

9

20Y-43-16510

RAIL, L.H. CONSOLE SLIDING

|$12

20Y-43-16380

CABLE

10

01580-10806

NUT

11

01643-30823

WASHER

12

20Y-43-16590

SCREW

13

01010-60820

BOLT

14

01580-10806

NUT

15

01643-70823

WASHER

16

20Y-43-16112

STAND, L.H. CONSOLE

17

01010-51225

BOLT

18

01643-31232

WASHER

19

205-43-72480

COVER

20

20Y-43-16121

COVER, L.H. STAND

21

01010-50820

BOLT

22

01643-30823

WASHER
