Запчасти Komatsu PC200-5 CRANKING МОТОР (.KW) ЭЛЕКТРИКА

Схема запчастей Komatsu PC200-5 - CRANKING МОТОР (.KW) ЭЛЕКТРИКА
7
16
8
12
11
17
13
16
24
14
10
5
6
9
15
2
21
6
22
1
3
4
23
19
20
18

Артикул

Название

Примечание

Количество

|$0

600-813-4420

MOTOR. CRANKING (5.5KW)

1

KD7-23100-0190

ARMATURE ASSEMBLY

2

KD1-0454-60047

BEARING, FRONT BALL

3

KD1-0454-62007

BEARING, REAR BALL

4

KD0-23230-0210

FIELD COIL ASSEMBLY

5

KD1-23785-0100

LEAD WIRE ASSEMBLY

6

KD7-23780-0170

TERMINAL ASSEMBLY

7

KD0-23310-0680

FRONT BRACKET ASSEMBLY

8

KD1-23351-0140

METAL

9

KD1-23111-0350

SHAFT ASSEMBLY

10

KD1-0454-60057

BEARING, BALL

11

KD1-23181-0030

STOPPER, PINION

12

KD1-23914-0030

RING, CLIP

13

KD0-23500-0390

CLUTCH ASSEMBLY, OVER RUNNING

14

KD0-23600-0220

CENTER BRACKET ASSEMBLY

15

KD1-23611-0430

BRACKET CENTER

16

KD7-23320-0040

SHIFT LEVER ASSEMBLY

17

KD0-47100-3510

MAGNETIC SWITCH ASSEMBLY

|$18

KD7-23700-0370

REAR BRACKET ASSEMBLY

18

KD0-23711-0170

BRACKET, REAR

19

KD1-23913-0010

SPRING, BRUSH

20

KD0-23750-0120

BRUSH HOLDER ASSEMBLY

21

KD1-23740-0170

BRUSH (+)

22

KD0-23740-0180

BRUSH (-)

23

KD1-23901-0080

BOLT

24

KD0-25000-7280

SWITCH ASSEMBLY

N/I

KD7-23920-0040

WASHER ASSEMBLY

N/I

KD7-09210-1390

SEAL ASSEMBLY

Выбрано товаров: 28
