Запчасти Komatsu PC200-5 ВОДЯНАЯ ПОМПА СИСТЕМА ОХЛАЖДЕНИЯ

|$0

6206-61-1103

WATER PUMP ASSEMBLY

|$1

6206-61-1102

WATER PUMP ASSEMBLY

1

NSS

BODY

2

6206-61-1341

SHAFT

2

6206-61-1340

SHAFT

3

6206-61-1411

BOSS

3

6206-61-1410

BOSS

4

6221-61-1520

SEAL, WATER

5

6206-61-1553

IMPELLER

6

6206-61-1120

COVER

7

6206-61-1130

GASKET

8

01236-40816

SCREW

9

203-977-4130

VALVE

9

6206-61-8620

TEE (WITH CORROSION RESISTOR TYPE)

10

07042-00312

PLUG

10

6136-55-7610

NIPPLE (WITH CORROSION RESISTOR TYPE)

11

7861-92-3320

SENSOR, ENGINE WATER TEMPERATURE

12

08036-10814

CLIP

13

07000-03040

O-RING

14

6206-61-1710

GASKET

15

01435-20855

BOLT

16

01435-20855

BOLT

16

01435-20875

BOLT (WITH ALTERNATOR TYPE COVER)

17

600-421-6110

THERMOSTAT

17

600-421-6120

THERMOSTAT

17

600-421-6110

THERMOSTAT

18

6140-11-6331

GASKET

19

6204-11-6430

CONNECTOR

20

01435-20820

BOLT

21

6207-61-3240

PULLEY, NON HARDENING

22

01435-20820

BOLT

23

04120-21750

V-BELT

23

04120-21750

V-BELT (FOR LARGE PULLEY)

23

04120-21749

V-BELT (FOR BRUSHLESS ALTERNATOR)
