Запчасти Komatsu PC200-5 ТОПЛ. НАСОС РЕГУЛЯТОР (EXTERNAL ASSEMBLY) ХОЛОДН. МЕСТН. ТОПЛИВН. СИСТЕМА

1

DK154011-0100

NUT, LOCK

2

DK154500-2020

COVER

3

DK154031-2400

SCREW

4

DK139206-0600

NUT

4

DK013020-6040

NUT

5

DK154036-0300

PLUG

6

DK020106-5040

BOLT

7

DK154010-0300

SCREW

8

DK020106-3840

BOLT

9

DK154063-6820

COVER

10

DK139008-0400

STUD

11

DK029020-6210

BOLT

12

DK020006-1640

BOLT

13

DK154150-0400

SPRING, GOVERNOR

14

DK154158-1520

CAPSULE, SPRING

15

DK154011-1700

NUT

16

DK026512-1540

GASKET

17

DK154159-1200

NUT, CAP

18

DK154200-7020

LEVER, SWIVEL

19

DK154204-3000

BUSHING

20

DK029631-8020

O-RING

21

DK016010-1640

RING, SNAP

22

DK139611-0000

SEAL, OIL

23

DK139411-0000

SHIM

24

DK029311-1090

SHIM, (0.3mm)

25

DK154204-3100

BUSHING

26

DK025803-1310

KEY

27

DK154206-2800

COLLAR

28

DK154206-0200

WASHER

29

DK154237-0100

PIN

30

DK154343-9220

LEVER

31

DK154350-7800

GASKET

32

DK029635-2020

O-RING

33

DK026506-1040

GASKET

34

DK154035-1600

NUT, CAP
