Запчасти Komatsu PC200-5 ТОПЛ. НАСОС РЕГУЛЯТОР (EXTERNAL ASSEMBLY) ДЛЯ ЭКСТРЕНН. СТОП СИСТЕМА ТОПЛИВН. СИСТЕМА

1

DK154011-0100

NUT, LOCK

2

DK154500-1020

COVER

3

DK154321-0400

BUSHING

4

DK154031-2400

SCREW

5

DK139206-0600

NUT

5

DK029240-6010

NUT

6

DK154036-0300

PLUG

7

DK020106-5040

BOLT

8

DK154010-0300

SCREW

9

DK020106-3840

BOLT

10

DK154063-6820

COVER

11

DK139008-0400

STUD

12

DK020006-1640

BOLT

13

DK029020-6210

BOLT

14

DK154150-0400

SPRING, GOVERNOR

15

DK154158-1520

CAPSULE, SPRING

16

DK154011-1700

NUT

17

DK026517-1540

GASKET

18

DK154159-1200

NUT

19

DK154200-7020

LEVER, SWIVEL

20

DK154204-3000

BUSHING

21

DK029631-8020

O-RING

22

DK016010-1640

RING, SNAP

23

DK139611-0000

SEAL, OIL

24

DK139411-0000

SHIM

25

DK029311-1090

SHIM, (0.3mm)

26

DK154204-3100

BUSHING

27

DK025803-1310

KEY

28

DK154206-2800

COLLAR

29

DK154206-0200

WASHER

30

DK154237-1100

PIN

31

DK154343-9220

LEVER

32

DK154380-0120

LEVER

33

DK020006-1640

BOLT

34

DK029631-0030

O-RING

35

DK154322-0100

CAP

36

DK154327-7600

SPRING

37

DK029311-0520

SHIM, (0.2mm)

37

DK029311-0530

SHIM, (0.25mm)

37

DK029311-0540

SHIM, (0.3mm)

37

DK029311-0550

SHIM, 0.35mm)

37

DK029311-0560

SHIM, (0.4mm)

37

DK029311-0570

SHIM, (0.5mm)

38

DK154350-7800

GASKET

39

DK029635-2020

O-RING

40

DK026506-1040

GASKET

41

DK154035-1600

NUT, CAP
