Запчасти Komatsu PC200-5 ТОПЛ. НАСОС ДЛЯ ЭКСТРЕНН. СТОП СИСТЕМА ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC200-5 - ТОПЛ. НАСОС ДЛЯ ЭКСТРЕНН. СТОП СИСТЕМА ТОПЛИВН. СИСТЕМА
16
49
15
17
50
8
13
51
50
14
4
12
11
5
1
28
3
33
48
38
36
47
27
46
7
35
6
37
34
42
2
54
45
32
9
53
31
43
39
10
52
41
29
40
30
25
24
26
44
23
22
18
21
20
19
8

Артикул

Название

Примечание

Количество

|$0

6209-71-1230

INJECTION PUMP ASSEMBLY

|$1

DK101069-9270

PUMP ASSEMBLY

1

DK131073-7520

HOUSING

2

DK029040-6020

STUD

3

DK131400-0100

ADAPTER

4

DK131423-0900

ADAPTER

5

DK131028-6020

COVER

6

DK131017-1000

SCREW

7

DK029340-6020

GASKET

8

DK131034-1401

PLUG

9

DK139206-0400

NUT

10

DK029633-1010

O-RING

11

DK131152-9320

PLUNGER ASSEMBLY

12

DK131110-6820

VALVE, DELIVERY

13

DK131112-4200

SPRING

14

DK131115-1600

GASKET

15

DK131116-8720

HOLDER, DELIVERY VALVE

16

DK131122-0520

PLATE ASSEMBLY

17

DK029632-0030

O-RING

18

DK131200-0220

TAPPET ASSEMBLY

19

DK131203-0200

PIN

20

DK131204-1000

ROLLER

21

DK131205-0500

BUSHING

22

DK131206-0200

GUIDE

23

DK029311-0580

SHIM, (0.2mm)

23

DK029311-0590

SHIM, (0.25mm)

23

DK029311-0020

SHIM, (O.30mm)

23

DK029311-0600

SHIM, (0.35mm)

23

DK029311-0030

SHIM, (0.40mm)

23

DK029311-0610

SHIM, (0.45mm)

23

DK029311-0040

SHIM, (0.50mm)

23

DK029311-0270

SHIM, (0.55mm)

23

DK029311-0050

SHIM, (0.6mm)

23

DK029311-0280

SHIM, (0.65mm)

23

DK029311-0060

SHIM, (0.7mm)

23

DK029311-0290

SHIM, (0.75mm)

23

DK029311-0070

SHIM, (0.8mm)

23

DK029311-0310

SHIM, (0.85mm)

23

DK029311-0080

SHIM, (0.9mm)

23

DK029311-0320

SHIM, (0.95mm)

23

DK029311-0090

SHIM, (1.0mm)

23

DK029311-0330

SHIM, (1.05mm)

23

DK029311-0110

SHIM, (1.1mm)

23

DK029311-0340

SHIM, (1.15mm)

23

DK029311-0120

SHIM, (1.2mm)

23

DK029311-0350

SHIM, (1.25mm)

23

DK029311-0130

SHIM, (1.3mm)

23

DK029311-0620

SHIM, (1.35mm)

23

DK029311-0140

SHIM, (1.4mm)

23

DK029311-0630

SHIM, (1.45mm)

23

DK029311-0490

SHIM, (1.5mm)

23

DK029311-0710

SHIM, (1.55mm)

23

DK029311-0500

SHIM, (1.6mm)

24

DK131215-2500

SPRING, PLUNGER

25

DK131216-0100

SEAT

26

DK131217-0200

SEAT

27

DK131256-0000

RACK, CONTROL

28

DK131226-0300

SCREW

29

DK131240-0100

PINION

30

DK131241-0100

SLEEVE, CONTROL

31

DK131242-0100

SCREW

32

DK131371-2800

CAMSHAFT

33

DK016630-2030

BEARING

33

DK028201-7020

BEARING

34

DK016640-2030

BEARING

34

DK028020-0020

BEARING

35

DK131302-1300

RING

36

DK131302-1700

RING

37

DK029312-0310

SHIM, (0.10mm)

37

DK029312-0320

SHIM, (0.12mm)

37

DK029312-0330

SHIM, (0.14mm)

37

DK029312-0340

SHIM, (0.16mm)

37

DK029312-0350

SHIM, (0.18mm)

37

DK029312-0360

SHIM, (0.3mm)

37

DK029312-0370

SHIM, (0.5mm)

37

DK029312-0380

SHIM, (1.0mm)

38

DK029311-7010

SHIM, (0.10mm)

38

DK029311-7020

SHIM, (0.12mm)

38

DK029311-7030

SHIM, (0.14mm)

38

DK029311-7040

SHIM, (0.16mm)

38

DK029311-7050

SHIM, (0.18mm)

38

DK029311-7090

SHIM, (0.30mm)

38

DK029311-7060

SHIM, (0.50mm)

38

DK029311-7210

SHIM, (0.70mm)

38

DK029311-7070

SHIM, (1.00mm)

38

DK029311-7220

SHIM, (1.40mm)

39

DK131306-0800

BEARING, CENTER

40

DK029050-5010

SCREW

41

DK026505-0940

GASKET

42

DK029622-0190

SEAL, OIL

43

DK131330-1800

COVER

44

DK020006-2040

BOLT

45

DK131321-1700

GASKET

46

DK029470-4030

KEY

47

DK029731-4680

BOLT, EYE

48

DK029341-4130

GASKET

49

DK131424-1520

VALVE, OVER FLOW

50

DK029341-4130

GASKET

51

DK131508-8920

EYE

52

DK029637-5020

O-RING

53

DK026731-0120

BOLT, EYE

54

DK029341-0110

GASKET

Выбрано товаров: 102
