Запчасти Komatsu PC200-5 ТОПЛ. НАСОС ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC200-5 - ТОПЛ. НАСОС ТОПЛИВН. СИСТЕМА
17
50
16
18
51
8
14
52
51
15
4
13
12
6
5
1
29
3
34
49
39
48
37
28
47
8
36
7
38
35
43
2
55
46
33
32
10
54
44
40
11
53
42
30
41
31
26
25
27
45
24
23
19
22
21
20
9

Артикул

Название

Примечание

Количество

|$0

6207-71-1211

INJECTION PUMP ASSEMBLY

|$1

6207-71-1262

INJECTION PUMP ASSEMBLY

|$2

DK101069-9400

PUMP ASSEMBLY

|$3

DK101069-9370

PUMP ASSEMBLY

1

DK131073-8520

HOUSING

1

DK131073-7520

HOUSING

2

DK029040-6020

STUD

3

DK131400-0100

ADAPTER

4

DK131423-0900

ADAPTER

5

DK131028-6020

COVER

6

DK131011-0800

GASKET

7

DK131017-1000

SCREW

8

DK029340-6020

GASKET

9

DK131034-1401

PLUG

10

DK139206-0400

NUT

11

DK029633-1010

O-RING

12

DK131152-2220

PLUNGER ASSEMBLY

12

DK131152-9320

PLUNGER ASSEMBLY

13

DK131110-6820

VALVE, DELIVERY

14

DK131112-4200

SPRING

15

DK131115-1600

GASKET

16

DK131116-8720

HOLDER, DELIVERY VALVE

17

DK131122-0520

PLATE ASSEMBLY

18

DK029632-0030

O-RING

19

DK131200-2820

TAPPET ASSEMBLY

19

DK131200-0220

TAPPET ASSEMBLY

20

DK131203-0800

PIN

20

DK131203-0200

PIN

21

DK131204-1000

ROLLER

22

DK131205-0500

BUSHING

23

DK131206-0200

GUIDE

24

DK029311-0580

SHIM, (0.2mm)

24

DK029311-0590

SHIM, (0.25mm)

24

DK029311-0020

SHIM, (O.30mm)

24

DK029311-0600

SHIM, (0.35mm)

24

DK029311-0030

SHIM, (0.40mm)

24

DK029311-0080

SHIM, (0.9mm)

24

DK029311-0310

SHIM, (0.85mm)

24

DK029311-0080

SHIM, (0.9mm)

24

DK029311-0320

SHIM, (0.95mm)

24

DK029311-0090

SHIM, (1.0mm)

24

DK029311-0330

SHIM, (1.05mm)

24

DK029311-0110

SHIM, (1.1mm)

24

DK029311-0340

SHIM, (1.15mm)

24

DK029311-0120

SHIM, (1.2mm)

24

DK029311-0350

SHIM, (1.25mm)

24

DK029311-0130

SHIM, (1.3mm)

24

DK029311-0620

SHIM, (1.35mm)

24

DK029311-0140

SHIM, (1.4mm)

24

DK029311-0630

SHIM, (1.45mm)

24

DK029311-0490

SHIM, (1.5mm)

24

DK029311-0710

SHIM, (1.55mm)

24

DK029311-0500

SHIM, (1.6mm)

25

DK131215-2500

SPRING, PLUNGER

26

DK131216-0100

SEAT

27

DK131217-0200

SEAT

28

DK131256-0000

RACK, CONTROL

29

DK131226-0300

SCREW

30

DK131240-0100

PINION

31

DK131241-0100

SLEEVE, CONTROL

32

DK131242-0100

SCREW

33

DK131371-3700

CAMSHAFT

33

DK131371-2800

CAMSHAFT

34

DK016630-2030

BEARING

35

DK016640-2030

BEARING

36

DK131302-1300

RING

37

DK131302-1700

RING

38

DK029312-0310

SHIM, (0.10mm)

38

DK029312-0320

SHIM, (0.12mm)

38

DK029312-0330

SHIM, (0.14mm)

38

DK029312-0340

SHIM, (0.16mm)

38

DK029312-0350

SHIM, (0.18mm)

38

DK029312-0360

SHIM, (0.3mm)

38

DK029312-0370

SHIM, (0.5mm)

38

DK029312-0380

SHIM, (1.0mm)

39

DK029311-7010

SHIM, (0.10mm)

39

DK029311-7020

SHIM, (0.12mm)

39

DK029311-7030

SHIM, (0.14mm)

39

DK029311-7040

SHIM, (0.16mm)

39

DK029311-7050

SHIM, (0.18mm)

39

DK029311-7090

SHIM, (0.30mm)

39

DK029311-7060

SHIM, (0.50mm)

39

DK029311-7210

SHIM, (0.70mm)

39

DK029311-7070

SHIM, (1.00mm)

39

DK029311-7220

SHIM, (1.40mm)

39

DK139417-0000

SHIM, (2.4mm)

40

DK131306-1000

BEARING, CENTER

40

DK131306-0800

BEARING, CENTER

41

DK029050-5010

SCREW

42

DK026505-0940

GASKET

43

DK029622-0190

SEAL, OIL

44

DK131330-1800

COVER

45

DK020006-2040

BOLT

46

DK131321-1700

GASKET

47

DK029470-4030

KEY

48

DK131401-0020

BOLT, EYE

48

DK029731-4680

BOLT, EYE

49

DK029341-4130

GASKET

50

DK131424-7420

VALVE, OVER FLOW

51

DK029341-4130

GASKET

52

DK131508-8920

EYE

53

DK029637-5020

O-RING

54

DK026731-0120

BOLT, EYE

55

DK029341-0110

GASKET

Выбрано товаров: 104
