Запчасти Komatsu PC200-5 КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

6207-31-1100

CRANKSHAFT ASSEMBLY

1

NSS

CRANKSHAFT

2

6204-31-1220

GEAR, CRANKSHAFT

3

6206-31-1530

KEY

4

6207-31-1430

PULLEY, NON HARDENING CRANKSHAFT

|$5

6207-31-1410

PULLEY, HARDENING CRANKSHAFT

5

6136-31-1420

COLLAR, TAPER

6

6136-31-1431

PLATE

7

01050-31845

BOLT

8

6206-31-8100

DAMPER

9

01435-01035

BOLT

|$11

6204-21-8100

MAIN BEARING ASSEMBLY (STANDARD)

10

NSS

BEARING, UPPER

11

NSS

BEARING, LOWER

|$14

6204-29-8100

MAIN BEARING ASSEMBLY (UNDERSIZE 0.25 MM)

10

NSS

BEARING, UPPER

11

NSS

BEARING, LOWER

|$17

6204-28-8100

MAIN BEARING ASSEMBLY (UNDERSIZE 0.50 MM)

10

NSS

BEARING, UPPER

11

NSS

BEARING, LOWER

12

6204-21-8600

THRUST BEARING ASSEMBLY (STANDARD)

|$21

6204-29-8600

THRUST BEARING ASSEMBLY (OVERSIZE 0.25 MM)

|$22

6204-28-8600

THRUST BEARING ASSMEBLY (OVERSIZE 0.50 MM)

|$23

6204-27-8600

THRUST BEARING ASSEMBLY (OVERSIZE 0.75 MM)

|$24

6204-26-8600

THRUST BEARING ASSEMBLY (OVERSIZE 1.00 MM)
