Запчасти Komatsu PC200-5 БЛОК ЦИЛИНДРОВ БЛОК ЦИЛИНДРОВ

|$0

6209-21-1100

BLOCK, CYLINDER ASSEMBLY

1

NSS

BLOCK, CYLINDER

2

6204-21-1410

BUSHING, CAMSHAFT

3

6206-21-1420

BUSHING, CAMSHAFT

4

6204-29-1210

CAP, MAIN BEARING (NO. 1, 2, 3, 4, 5, 6)

5

6204-29-1220

CAP, MAIN BEARING (NO. 7)

6

6141-21-1530

RING, DOWEL

7

04025-00408

PIN, SPRING

8

6204-21-1610

BOLT, MAIN CAP

9

6204-51-1711

BUSHING, OIL PUMP

10

6209-51-1620

SHAFT, OIL PUMP

11

07046-41810

PLUG

12

04020-00820

PIN, DOWEL

13

6136-52-1620

PIN, DOWEL

14

07046-42216

PLUG

15

04020-01228

PIN, DOWEL

16

07046-43016

PLUG

17

07046-42516

PLUG

18

07042-00312

PLUG

19

07043-50108

PLUG

20

07043-50211

PLUG

21

6140-21-1130

BUSHING, DOWEL

22

6207-21-1190

PIN

23

07046-44016

PLUG

24

07046-23016

PLUG

25

08073-00505

SWITCH, OIL PRESSURE

26

6204-21-5510

GUIDE, BASE

27

6150-21-5930

NUT

28

6150-21-5920

COLLAR

29

6207-21-5410

GUIDE, OIL GAUGE

30

6207-21-5314

GAUGE, OIL

31

6206-21-5520

CLIP

32

6207-21-5450

BRACKET

33

01435-20816

BOLT, CYLINDER ASSEMBLY

34

01642-20810

WASHER

35

01584-00806

NUT

36

195-49-36120

NIPPLE (QUICK DISCONNECT)

37

6207-21-2110

LINER, CYLINDER (MARK A)

|$38

6207-21-2120

LINER, CYLINDER (MARK B)
