Запчасти Komatsu PC200-5 ЦИЛИНДР КОВША ДЛЯ FOOT УДЛИНН. СТРЕЛА РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|$0

203-63-02130

CYLINDER ASSEMBLY, BUCKET - FOR 50 FOOT LONG BOOM

1

203-63-74340

CYLINDER

2

707-76-65210

BUSHING

3

07145-00065

SEAL, DUST

4

07020-00675

FITTING, GREASE

5

707-27-95620

HEAD, CYLINDER

6

707-52-90400

BUSHING

7

707-51-65030

PACKING, ROD

8

707-51-65630

RING, BUFFER

9

07000-15090

O-RING

10

07001-05090

RING, BACK-UP

11

144-63-92170

SEAL, DUST

12

07179-12079

RING, SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

203-63-74320

ROD, PISTON

16

707-76-65220

BUSHING

17

707-77-65110

SEAL, DUST

18

07020-00675

FITTING, GREASE

19

707-36-95410

PISTON

20

707-44-95180

RING, PISTON

21

707-39-95120

RING, WEAR

22

707-44-95911

RING

23

07165-14547

NUT, NYLON

24

202-63-74371

TUBE

25

202-63-74381

TUBE

26

07000-13025

O-RING

27

01010-50850

BOLT

28

01643-50823

WASHER

29

707-88-96250

BAND

30

707-88-95531

BRACKET

31

01010-51035

BOLT

32

01643-51032

WASHER

33

707-88-96260

BAND

34

203-63-74390

BRACKET

35

07283-22236

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER

|$38

707-98-36210

SERVICE KIT, BUCKET CYLINDER

3

07145-00065

SEAL, DUST

7

707-51-65030

PACKING, ROD

8

707-51-65630

RING, BUFFER

9

07000-15090

O-RING

10

07001-05090

RING, BACK-UP

11

144-63-92170

SEAL, DUST

17

707-77-65110

SEAL, DUST

20

707-44-95180

RING, PISTON

21

707-39-95120

RING, WEAR

26

07000-13025

O-RING
