Запчасти Komatsu PC200-5 ЦИЛИНДР СТРЕЛЫДЛЯ FOOT УДЛИНН. СТРЕЛА РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|$0

206-63-02100

CYLINDER ASSEMBLY, BOOM - FOR 50 FOOT LONG BOOM

1

206-63-53340

CYLINDER

2

206-70-55280

BUSHING

3

07145-00080

SEAL DUST

4

206-63-53320

ROD, PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL, DUST

7

707-27-13620

HEAD, CYLINDER

8

07179-13104

RING, SNAP

9

195-63-94170

SEAL, DUST

10

707-52-90650

BUSHING

11

707-51-90030

PACKING, ROD

12

07000-15125

O-RING

13

07001-05125

RING, BACK-UP

14

707-51-90630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13411

PISTON

18

707-44-13180

RING, PISTON

19

707-39-13110

RING, WEAR

20

707-44-13911

RING

21

707-40-13470

RETAINER

22

707-71-60911

PLUNGER

23

07165-16870

NUT

24

707-71-32610

COLLAR

25

07001-05125

RING, BACK-UP

26

07000-15125

O-RING

27

206-63-53371

TUBE, L.H

|$28

206-63-53471

TUBE, R.H

28

206-63-53381

TUBE, L.H

|$30

206-63-53481

TUBE, R.H

29

07372-21060

BOLT

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING

33

707-88-95182

BRACKET, L.H

|$36

707-88-95192

BRACKET, R.H

34

707-88-95081

BAND

35

01010-51035

BOLT

36

01643-51032

WASHER

37

07283-22738

CLIP

38

01599-01011

NUT

39

01643-31032

WASHER
