Запчасти Komatsu PC200-5 ЦИЛИНДР СТРЕЛЫS (8-FOOT, 8-INCH СТРЕЛА) РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|$0

205-63-02100

CYLINDER ASSEMBLY, BOOM

1

205-63-53340

CYLINDER

2

205-70-71360

BUSHING

3

07145-00070

SEAL, DUST

4

205-63-53320

ROD, PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL, DUST

7

707-27-12620

HEAD, CYLINDER

8

07179-13099

RING, SNAP

9

707-56-85510

SEAL, DUST

10

707-52-90600

BUSHING

11

707-51-85030

PACKING, ROD

12

07000-15115

O-RING

13

07001-05115

RING, BACK-UP

14

707-51-85630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12411

PISTON

18

707-44-12180

RING, PISTON

19

707-39-12110

RING, WEAR

20

707-44-12911

RING

21

707-71-60901

PLUNGER

22

07165-15860

NUT

23

707-71-32600

COLLAR

24

07001-05115

RING, BACK-UP

25

07000-15115

O-RING

26

205-63-53371

TUBE, L.H

26

205-63-53471

TUBE, R.H

27

205-63-53381

TUBE, L.H

27

205-63-53481

TUBE, R.H

28

07372-21060

BOLT

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING

32

707-88-95161

BRACKET, L.H

32

707-88-95171

BRACKET, R.H

33

707-88-96530

BAND

34

01010-51035

BOLT

35

01643-51032

WASHER

36

07283-22738

CLIP

37

01599-01011

NUT

38

01643-31032

WASHER
