Запчасти Komatsu PC200-5 СОЛЕНОИДНЫЙ КЛАПАН ТРУБЫ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

20Y-62-17620

HOSE, SWING MOTOR TO HIGH-LOW VALVE

2

20Y-62-17720

ELBOW

3

07042-30108

PLUG

4

07002-01423

O-RING

5

205-62-55270

NIPPLE

6

21T-62-29960

TEE

7

07002-01423

O-RING

8

702-16-51890

FILTER ASSEMBLY

9

07002-02034

O-RING

10

706-46-56290

BOLT, EYE

11

07002-02018

O-RING

12

20Y-62-17580

HOSE, TEE TO HIGH-LOW VALVE

13

20Y-62-15683

BRACKET

13

20Y-970-1870

BRACKET

14

01010-51225

BOLT

15

01643-31232

WASHER

16

08036-21014

CLIP

17

01010-51225

BOLT

18

01643-31232

WASHER

|$19

20Y-62-15711

HOSE ASSEMBLY

19

20Y-62-17660

HOSE (RED), HIGH-LOW TRAVEL VALVE TO PUMP

20

20Y-62-17150

HOSE (BLUE), HIGH-LOW VALVE TO CONTROL VALVE

|$22

07102-20412

HOSE (YELLOW), CHARGING PUMP TO TEE

21

20Y-62-11780

TEE

22

07002-01423

O-RING

23

20Y-62-17380

HOSE, FRONT SERVO TO REAR SERVO

24

207-62-33920

ELBOW

25

07002-01423

O-RING

26

20Y-62-17120

TEE

27

07002-01643

O-RING

28

20Y-62-17370

HOSE, CONNECTING FOUR SPOOL AND FIVE SPOOL VALVES

29

20Y-62-11940

ELBOW

30

07002-01623

O-RING

31

141-06-11220

CLIP

32

01010-51225

BOLT

33

01643-31232

WASHER
