Запчасти Komatsu PC200-5 P.P.C. КЛАПАН ТРУБЫ РАСПРЕДЕЛИТ. КЛАПАН TO/FROM УПРАВЛЯЮЩ. КЛАПАН - ЗАДН. УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

20Y-62-15761

HOSE ASSEMBLY

1

07102-20311

HOSE (BLACK), R.H. SHUTTLE VALVE TO CONTROL VALVE

2

20Y-62-17170

HOSE (WHITE), R.H. SHUTTLE VALVE TO CONTROL VALVE

3

20Y-62-17230

HOSE (GREEN), L.H. SHUTTLE VALVE TO CONTROL VALVE

4

20Y-62-17170

HOSE, L.H. SHUTTLE VALVE TO CONTROL VALVE

5

07102-20313

HOSE (YELLOW),

6

20Y-62-17230

HOSE (BROWN),

|$9

20Y-62-15811

HOSE ASSEMBLY

7

07102-20308

HOSE (BROWN), R.H. SHUTTLE VALVE TO CONTROL VALVE

8

20Y-62-17250

HOSE (YELLOW), R.H. SHUTTLE VALVE

9

20Y-62-17390

HOSE (RED), L.H. SHUTTLE VALVE TO CONTROL VALVE

10

20Y-62-17260

HOSE (BLUE), L.H. SHUTTLE VALVE TO CONTROL VALVE

11

07102-20306

HOSE (WHITE), L.H. SHUTTLE VALVE TO CONTROL VALVE

12

20Y-62-17390

HOSE (BLACK), L.H. SHUTTLE VALVE TO CONTROL VALVE

13

205-62-55270

NIPPLE

14

07002-01423

O-RING

15

207-62-33920

ELBOW

16

07002-01423

O-RING

17

20Y-62-11780

ELBOW

18

07002-01423

O-RING

19

20Y-62-17390

HOSE, R.H. SHUTTLE VALVE TO CONTROL VALVE

20

207-62-33950

NIPPLE

21

07002-01423

O-RING

22

207-62-33920

ELBOW

23

07002-01423

O-RING

24

20Y-62-17390

HOSE, L.H. SHUTTLE VALVE TO CONTROL VALVE

25

20Y-62-15891

CLIP

26

01010-51220

BOLT

27

01643-31232

WASHER

28

08034-00536

BAND

29

07230-20315

UNION

30

07002-02034

O-RING

31

20Y-62-17450

NIPPLE

32

207-62-33950

NIPPLE

33

207-62-53790

ELBOW

34

20Y-62-17380

HOSE, R.H. SHUTTLE VALVE TO CONTROL VALVE

35

207-62-33920

ELBOW

36

22X-61-18550

ELBOW
