Запчасти Komatsu PC200-5 P.P.C. КЛАПАН ТРУБЫ РАСПРЕДЕЛИТ. КЛАПАН TO/FROM УПРАВЛЯЮЩ. КЛАПАН УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

01010-51070

BOLT

2

01643-31032

WASHER

3

702-19-12000

VALVE ASSEMBLY, CHECK

4

07040-11409

PLUG

5

07002-01423

O-RING

6

07002-01423

O-RING

7

205-62-55270

NIPPLE

8

22X-61-18550

ELBOW

9

21T-62-29960

NIPPLE

|$9

20Y-970-1661

HOSE ASSEMBLY

10

20Y-62-17220

HOSE (RED), SHUTTLE TO CHECK VALVE

11

20Y-62-17260

HOSE (BLUE), CONTROL TO CHECK VALVE

12

20Y-62-17220

HOSE (YELLOW), CONTROL TO CHECK VALVE

13

20Y-62-17170

HOSE, CONTROL TO CHECK VALVE

14

22X-61-18550

ELBOW

15

207-62-33920

ELBOW

16

07002-01423

O-RING

17

113-899-7950

CLIP

18

08036-21414

CLIP

19

01010-51225

BOLT

20

01643-31232

WASHER

21

21T-62-74610

ELBOW

22

07002-02434

O-RING

23

20Y-970-2210

HOSE, CROSS VALVE TO SWING MOTOR

24

20Y-970-2230

HOSE, MAIN FILTER TO SWING MOTOR

25

08035-03014

CLIP

26

01010-51225

BOLT

27

01643-31232

WASHER

28

07235-10628

ELBOW

29

07002-02434

O-RING

30

20Y-62-17620

HOSE, HIGH LOW VALVE TO CHECK VALVE

31

20Y-62-11780

ELBOW

32

07002-01423

O-RING
