Запчасти Komatsu PC200-5 P.P.C. КЛАПАН ТРУБЫ БЛОК TO/FROM РАСПРЕДЕЛИТ. КЛАПАН УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

04102-20306

HOSE

2

20R-62-22260

ELBOW

3

20Y-62-16330

ELBOW

4

20Y-62-16340

ELBOW

5

20Y-62-16320

ELBOW

6

07002-02034

O-RING

|$6

20y-62-16230

HOSE ASSEMBLY, LEFT HAND

7

20Y-62-16250

HOSE (YELLOW), BLOCK TO L.H. SHUTTLE VALVE

8

07102-20321

HOSE (WHITE), BLOCK TO L.H. SHUTTLE VALVE

9

07102-20321

HOSE (BROWN), BLOCK TO L.H. SHUTTLE VALVE

10

20Y-62-16250

HOSE (BLACK), BLOCK TO L.H. SHUTTLE VALVE

11

07102-20311

HOSE

12

07236-10315

ELBOW

13

07002-02034

O-RING

|$14

20Y-62-16240

HOSE ASSEMBLY, RIGHT HAND

14

20Y-62-16260

HOSE (WHITE), BLOCK TO R.H. SHUTTLE VALVE

15

07102-20318

HOSE (YELLOW), BLOCK TO R.H. SHUTTLE VALVE

16

07102-20318

HOSE (BLACK), BLOCK TO R.H. SHUTTLE VALVE

17

20Y-62-16260

HOSE (BROWN), BLOCK TO R.H. SHUTTLE VALVE

18

142-06-13540

CLIP

19

20Y-62-15951

CLIP

20

20Y-62-15891

CLIP

21

20Y-03-11530

CLIP

22

01010-51225

BOLT

23

01643-31232

WASHER

24

207-62-33950

NIPPLE

25

07002-01423

O-RING

26

20Y-62-15631

BRACKET

26

20Y-970-2580

BRACKET

27

01010-51235

BOLT

28

01643-31232

WASHER

29

20Y-62-15971

CLIP

30

01010-51225

BOLT

31

01643-31232

WASHER

32

08036-01814

CLIP

33

08035-02512

CLIP

34

01010-51225

BOLT

35

01643-31232

WASHER

36

01010-51075

BOLT

37

01643-31032

WASHER
