Запчасти Komatsu PC200-5 МОТОР ПОВОРОТА ТОРМОЗ. КОРПУС УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

706-75-01081

MOTOR ASSEMBLY, SWING

1

706-75-41091

BLOCK, CYLINDER

2

706-75-41163

SUB ASSEMBLY, PISTON

3

706-75-42180

SHAFT, CENTER

4

706-75-41220

BALL CENTER

5

706-75-41110

SPRING

6

706-75-41130

RING, CENTER

7

706-75-40010

BEARING

8

706-75-42740

PLATE, VALVE

9

04020-00820

PIN, DOWEL

10

706-75-42260

RETAINER

11

706-75-42661

SHAFT, DRIVE

12

706-75-42270

SCREW

13

706-75-42121

CASE, BRAKE

14

706-75-42880

BEARING

15

706-76-40890

BEARING

16

706-7E-11260

SPRING

17

706-7E-11270

SEAT

18

706-75-05010

SPACER, KIT

19

04064-04518

RING, SNAP

20

706-75-42711

COVER

21

706-7E-11280

SEAL, OIL

22

07000-02085

O-RING

23

04065-09030

RING, SNAP

24

706-75-92180

PISTON, BRAKE

25

07000-15155

O-RING

26

07000-15175

O-RING

27

07000-05200

O-RING

28

706-75-92140

PLATE

29

706-75-92150

DISK

30

706-75-92130

PLATE

31

706-87-50360

BOLT
