Запчасти Komatsu PC200-5 МОТОР ХОДА МОТОР И ТОРМОЗ. УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

708-8H-12110

SHAFT, TRAVEL MOTOR

2

708-8H-12151

BEARING

3

708-8H-12141

BEARING

4

708-27-22810

SEAL

|$6

708-8H-05010

KIT, SPACER

5

NSS

SPACER .0440 (1.5 mm)

5

NSS

SPACER .0510 (1.6 mm)

5

NSS

SPACER .0580 (1.7 mm)

5

NSS

SPACER .0550 (1.8 mm)

5

NSS

SPACER .0720 (1.9 mm)

5

NSS

SPACER .0787 (2.0 mm)

5

NSS

SPACER .0825 (203 mm)

5

NSS

SPACER .0860 (2.1 mm)

5

NSS

SPACER .0930 (2.2 mm)

6

708-8H-12260

PLATE

7

708-8H-13110

BLOCK, CYLINDER

8

708-8H-13211

PLATE, VALVE

9

708-8H-13520

SPRING

|$20

708-8H-05020

KIT, SHIM

10

NSS

SHIM .0197 (0.5 mm)

10

NSS

SHIM .0088 (0.2 mm)

10

NSS

SHIM .0044 (0.1 mm)

11

708-8H-13510

RETAINER

12

708-8H-13340

SHOE, RETAINER

13

708-8H-13311

PISTON ASSEMBLY

|$27

708-8H-04132

CRADLE ASSEMBLY

14

708-8H-13811

CRADLE

15

708-8H-13432

ROCKER, CAM

16

708-8H-15240

BRAKE, PISTON

17

07000-15190

O-RING

18

07001-05190

RING

19

708-8H-15220

O-RING

20

708-8H-15230

RING, BACK-UP

21

708-8H-15150

SPRING

22

708-8H-15160

SPACER

23

708-8H-15130

PLATE, BRAKE

24

708-8H-15121

DISK, BRAKE

25

708-8H-13910

BOLT

26

708-8H-13920

SEAL, WASHER
