Запчасти Komatsu PC200-5 ГИДР. НАСОС. ASSEMBLY ОСНОВН. НАСОС ASSEMBLY - ЗАДН. SECTION УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$4

708-25-00100

CASE ASSEMBLY, MAIN PUMP ASSEMBLY - REAR

1

NSS

CASE, REAR

2

NSS

PLUG

|$7

708-25-00041

CRADLE ASSEMBLY, MAIN PUMP ASSEMBLY - REAR

|$8

708-25-00490

CRADLE SUB ASSEMBLY, MAIN REAR PUMP

3

NSS

CRADLE, REAR PUMP

4

NSS

PLUG

5

708-25-13411

CAM, ROCKER

6

708-25-12330

JOINT

7

07000-22015

O-RING

8

708-25-12340

O-RING

9

708-25-12350

BOLT

10

708-25-12360

PLATE

11

04020-00820

PIN, DOWEL

12

01010-30816

BOLT

13

708-25-32720

SHAFT, REAR

14

708-25-12731

BEARING

15

708-25-05010

WASHER KIT

16

708-25-12790

RING, SNAP

|$23

708-25-00411

BLOCK ASSEMBLY, CYLINDER

|$24

708-25-00410

BLOCK ASSEMBLY, CYLINDER

17

708-25-13151

BLOCK, CYLINDER

18

708-25-13621

PLATE, VALVE

18

708-25-13620

PLATE, VALVE

19

708-25-13630

RING

20

708-25-13422

RETAINER, SHOE

21

708-25-13120

WASHER

22

708-25-13130

SPRING

23

708-25-13140

RING, SNAP

24

708-25-13312

PISTON SUB ASSEMBLY

25

708-25-05061

SPACER KIT

26

708-25-13441

RETAINER

27

708-25-13470

SCREW

28

01643-30623

WASHER

29

708-25-14112

PISTON

30

708-25-14140

CAP

31

708-25-14150

CAP

32

708-25-14121

SLIDER

33

708-25-14130

SPRING

34

708-25-05050

SHIM KIT

35

07000-02065

O-RING

36

01016-30135

BOLT

37

01643-31032

WASHER

38

720-68-19870

PLUG, DRAIN

39

07002-01223

O-RING

40

708-25-12970

RING, SNAP

41

07044-02412

PLUG

42

07002-02434

O-RING

43

04530-01018

EYE BOLT
