Запчасти Komatsu PC200-5 ГИДР. НАСОС. ASSEMBLY ОСНОВН. НАСОС ASSEMBLY - ПЕРЕДН. SECTION УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$1

708-25-04151

FRONT SECTION, MAIN PUMP ASSEMBLY

|$2

708-25-04112

FRONT SECTION, MAIN PUMP ASSEMBLY

|$3

708-25-00630

CASE ASSEMBLY, FRONT

|$4

708-25-00471

CASE ASSEMBLY, FRONT

1

NSS

CASE, FRONT

2

NSS

PLUG, FRONT

|$7

708-25-00031

CRADLE ASSEMBLY, FRONT

|$8

708-25-00480

CRADLE SUB ASSEMBLY, FRONT

3

NSS

CRADLE, FRONT

4

NSS

PLUG

5

708-25-13411

CAM, ROCKER

6

708-25-12330

JOINT

7

07000-22015

O-RING

8

708-25-12340

O-RING

9

708-25-12390

BOLT

10

708-25-12360

PLATE

11

04020-00820

PIN, DOWEL

12

01010-30816

BOLT

13

708-25-12711

SHAFT, FRONT

14

708-25-12730

BEARING

15

708-25-05010

WASHER KIT

16

708-25-12790

RING, SNAP

17

708-25-12812

HOUSING

18

708-25-52860

SEAL, OIL

19

708-25-05130

SHIM, KIT

20

01010-30820

BOLT

21

01643-30823

WASHER

22

07000-02080

O-RING

|$29

708-25-00401

BLOCK ASSEMBLY, CYLINDER

|$30

708-25-00400

BLOCK ASSEMBLY, CYLINDER

23

708-25-13151

BLOCK, CYLINDER

24

708-25-13611

PLATE, VALVE

24

708-25-13610

PLATE, VALVE

25

708-25-13630

RING

26

708-25-13422

RETAINER, SHOE

27

708-25-13120

WASHER

28

708-25-13130

SPRING

29

708-25-13140

RING, SNAP

30

708-25-13441

RETAINER

31

708-25-13470

SCREW

32

01643-30623

WASHER

33

708-25-13312

PISTON SUB ASSEMBLY

34

708-25-05061

SPACER KIT

35

708-25-14211

PISTON

36

708-25-14140

CAP

37

708-25-14150

CAP

38

708-25-14121

SLIDER

39

708-25-14130

SPRING

40

708-25-05050

SHIM KIT

41

07000-02065

O-RING

42

01016-31035

BOLT

43

01643-31032

WASHER

44

720-68-19870

PLUG, DRAIN

45

07002-01223

O-RING

46

708-25-12970

RING, SNAP

47

07044-02412

PLUG, DRAIN

48

07002-02434

O-RING

49

07040-11209

PLUG, DRAIN

50

07002-01223

O-RING

51

04530-01018

BOLT, EYE
