Запчасти Komatsu PC20-6 ГИДРОЛИНИЯ (ИЗ НАСОСА В КЛАПАН) (ДЛЯ МОЛОТА) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

20S-62-31260

HOSE

|1

20S-62-31230

HOSE

2

20S-62-31250

HOSE

|2

20S-62-31220

HOSE

3

20S-62-31240

HOSE

|3

20S-62-31210

HOSE

4

07000-12021

O-RING

5

203-62-32440

COVER

6

07371-30400

FLANGE,SPLIT

7

01010-50830

BOLT

8

01602-20825

WASHER,SPRING

9

20R-62-21520

ELBOW

10

07002-12034

O-RING

11

20R-62-21510

ELBOW

12

07235-10422

ELBOW

13

20T-62-61230

TUBE

14

07002-12034

O-RING

15

08037-03614

GROMMET

16

709-32-12302

VALVE ASS'Y,(SEE FIG.6211)

|16

709-32-12301

VALVE ASS'Y,(SEE FIG.6211)

17

709-33-11503

VALVE ASS'Y,(FOR 2ND TRAVEL SPEED) (OP)

|17

709-33-11502

VALVE ASS'Y,(FOR 2ND TRAVEL SPEED) (OP)

|17

709-33-11501

VALVE ASS'Y,(FOR 2ND TRAVEL SPEED) (OP)

|17

709-33-11500

VALVE ASS'Y,(FOR 2ND TRAVEL SPEED) (OP)

18

709-36-12203

VALVE ASS'Y,(SEE FIG.6203)

|18

709-36-12202

VALVE ASS'Y,(SEE FIG.6203)

|18

709-36-12201

VALVE ASS'Y,(SEE FIG.6203)

|18

709-36-12200

VALVE ASS'Y,(SEE FIG.6203)

19

01010-50825

BOLT

20

01602-20825

WASHER,SPRING

21

20S-60-31211

BRACKET

|21

20S-60-31210

BRACKET

22

203-62-58360

CUSHION

|22

203-62-42770

CUSHION

23

20X-62-21550

SPACER

24

07000-03025

O-RING

|24

07000-03025

O-RING

25

566-35-42430

PLATE

26

01010-51250

BOLT

27

01643-31232

WASHER

G-1

20S-970-X170

CONTROL VALVE GROUP,(FOR BREAKER)

28

709-21-11200

VALVE ASS'Y,(FOR BREAKER)

29

20S-970-3410

BRACKET

30

01010-50820

BOLT

31

01602-20825

WASHER,SPRING

32

01010-51020

BOLT

33

01643-31032

WASHER

G-2

20S-970-X180

CONTROL PLUG GROUP

34

709-32-11860

PLUG

35

07002-02434

O-RING

36

700-22-11410

O-RING
