СТАРТЕР, . KW

Запчасти Komatsu PC195LC-8 СТАРТЕР, . KW A

Схема запчастей Komatsu PC195LC-8 - СТАРТЕР, . KW A
32
5
4
6
1
23
22
34
31
24
40
3
2
19
18
17
16
16
36
27
29
28
30
15
37
15
35
11
10
8
9
42
13
7
38
39
33
41
21
20
14
26
25
12
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

600-863-4210

STARTING MOTOR ASS'Y, 4.5 KW

1

YOKE ASS'Y

2

COVER

3

STARTING MOTOR KIT

4

ARMATURE ASS'Y

5

BEARING, BALL

6

BEARING, BALL

|$8

CLUTCH ASS'Y

7

STARTING MOTOR KIT

8

CLUTCH ASS'Y

9

BEARING, BALL

10

BEARING, BALL

11

SPRING

12

SHAFT

13

HOUSING ASS'Y

14

SWITCH ASS'Y

15

STARTING MOTOR KIT

16

STARTING MOTOR KIT

17

PLUNGER

18

GASKET

19

COVER

20

BOLT ASS'Y

21

BUSHING

22

BRUSH HOLDER ASS'Y

23

SPRING

24

FRAME

25

BALL

26

SPRING

27

PINION

28

ROLLER

29

RETAINER

30

RETAINER

31

BOLT

32

WASHER

33

O-RING

34

SCREW

35

NUT

36

NUT

37

WASHER, SPRING

38

SCREW

39

WASHER

40

COVER

41

SCREW

42

SEAL
