Запчасти Komatsu PC195LC-8 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ)(ДЛЯ РУКОЯТИ .9M, 100 ЧАСОВ СИСТ. СМАЗКИ) T

|$1

707-01-0CK51

BUCKET CYLINDER

1

707-13-10770

CYLINDER

2

721-58-70590

ROD, PISTON

3

707-76-70230

BUSHING

4

07145-00070

SEAL, DUST (KIT-K06)

5

07020-00000

FITTING, GREASE

6

707-76-70370

BUSHING

7

20Y-70-23220

SEAL, DUST (KIT-K06)

8

07020-00000

FITTING, GREASE

9

707-27-10750

HEAD, CYLINDER

10

707-56-70770

SEAL, DUST (KIT-K06)

11

707-56-70800

SEAL, DUST (KIT-K06)

12

707-51-70860

PACKING, ROD (KIT-K06)

13

707-88-39460

PLATE

14

707-88-41720

COLLAR

15

707-51-70650

RING, BUFFER (KIT-K06)

16

707-52-90471

BUSHING

17

707-75-70110

RING, SNAP

18

07000-B5095

O-RING (KIT-K06)

19

707-35-30960

RING, BACK-UP (KIT-K06)

20

01010-81495

BOLT

21

705-17-04980

WASHER

22

707-36-10760

PISTON

23

707-44-10250

RING, PISTON (KIT-K06)

24

707-39-10550

RING, WEAR (KIT-K06)

25

707-44-10911

RING

26

01310-01216

SCREW

27

707-34-60070

O-RING (KIT-K06)

28

707-35-30630

RING, BACK-UP (KIT-K06)

29

707-86-48880

TUBE

30

02896-61015

O-RING (KIT-K06)

31

707-88-22940

BRACKET

32

707-88-21650

BAND

33

07372-21035

BOLT

34

01643-51032

WASHER

35

07283-32236

CLIP

36

01597-01009

NUT

37

01643-31032

WASHER

38

01010-80850

BOLT

39

01643-30823

WASHER

40

07000-13025

O-RING (KIT-K06)

41

02789-00522

PLUG

42

07371-30640

FLANGE

43

707-88-33030

CAP
