Запчасти Komatsu PC195LC-8 КОРПУС (R.H) M

1

21K-54-73522

CASE

2

21K-54-73560

SEAL

3

203-54-67760

SEAL

4

203-54-67780

SEAL

5

21K-54-73580

BRACKET

6

01010-81230

BOLT

7

01643-31232

WASHER

8

203-54-56630

ROD

9

01643-30623

WASHER

10

04052-20633

PIN

11

11Y-06-11372

WORK LAMP ASSY

|$12

421-06-23330

BULB, 70WATT

12

08037-12536

GROMMET

13

21T-06-11351

TANK

14

01010-80616

BOLT

15

209-72-12230

WASHER

16

21K-54-73533

COVER

17

20Y-54-74161

HINGE, (WELDED)

18

20Y-54-74172

LOCK, (WELDED)

19

20Y-54-74182

LOCK ASS'Y

20

21K-54-73590

PLATE

21

01010-81020

BOLT

22

01643-31032

WASHER

23

21K-00-71370

PLATE

24

20Y-00-42140

PLATE

25

01010-81020

BOLT

26

01643-31032

WASHER

27

01010-81230

BOLT

28

124-54-26540

WASHER

29

14X-54-12590

CAP

30

21K-54-73541

COVER

31

01010-81230

BOLT

32

01643-31232

WASHER

33

01010-81230

BOLT

34

124-54-26540

WASHER

35

20Y-54-61670

BRACKET

36

20Y-54-61680

BRACKET

37

01010-81230

BOLT

38

01643-31232

WASHER
