Запчасти Komatsu PC190LC-8 РУКОЯТЬ, .M, РУКОЯТЬ РУКОЯТЬ, .M

|$0

21K-70-01001

Arm Assembly

1

Arm

2

21K-70-72C80

Seat,Welded

3

20Y-970-3560

Bracket,Welded

4

20Y-970-3570

Bracket,Welded

5

20J-70-12180

Seat,Welded

6

20J-47-11250

Seat,Welded

7

21K-70-72410

Seat,Welded

8

21K-70-72270

Bushing

9

205-70-73180

Bushing

10

21K-70-72290

Bushing

11

07020-00000

Fitting, Grease

12

07020-00900

Fitting, Grease

13

20Y-70-23220

Seal, Dust

14

20Y-70-23220

Seal, Dust

15

07145-00080

Seal, Dust

16

20Y-70-31161

Pin

17

205-70-66581

Plate

18

01010-81230

Bolt

19

01643-31232

Washer

20

21K-70-71650

Spacer, 1.0mm

21

21K-70-71192

Pin

22

205-70-66581

Plate

23

01010-81230

Bolt

24

01643-31232

Washer

25

21K-70-71630

Spacer, 1.0mm

26

21K-70-71640

Spacer, 2.0mm
