Запчасти Komatsu PC190LC-8 DIESEL ЧАСТЬICULATE ФИЛЬТР. И КРЕПЛЕНИЕ DIESEL ЧАСТЬICULATE ФИЛЬТР. И КРЕПЛЕНИЕ

1

21K-01-K1140

Diesel Particulate Filter Assy

2

20Y-01-K2030

Gasket

3

20Y-01-K2040

Ring Clamp

4

20Y-01-K2050

Plug

5

20Y-01-K2060

Mount

6

01435-01030

Bolt

7

01435-00614

Bolt

8

21K-01-K1210

Plate

9

21K-01-K1230

Flange

10

21K-01-K1240

Tube

11

21K-01-K1310

Clamp

12

21K-01-K1151

Bracket

13

01252-81060

Bolt

14

01643-31032

Washer

15

01010-81060

Bolt

16

01643-31032

Washer

17

01435-01030

Bolt

18

20Y-01-K2161

Hose (Pressure Sensor)

19

20Y-01-K2250

Sealing Ring

20

20Y-01-K2122

Pressure Sensor

21

20Y-01-K2111

Temperature Sensor

22

20Y-01-K2250

Sealing Ring

23

207-01-K1090

Fitting

24

207-01-K1080

Fitting

25

207-01-K1650

Water Seperator

26

20Y-01-K2291

Bracket

27

01023-70410

Screw

28

01010-81230

Bolt

29

01643-31032

Washer

30

04434-51712

Clip

31

08034-20536

Band

32

08034-20536

Band

33

20Y-01-K2150

Link Harness

34

04434-51212

Clip

35

08193-21012

Clip

36

21K-01-K1290

Tube

37

6151-53-8280

Clip

38

07285-00155

Clamp

39

07260-20950

Hose

40

207-01-K1690

Filter Bag
