Запчасти Komatsu PC18MR-3 РУКОЯТЬ, РУКОЯТЬ И ПАЛЕЦ (№-) РУКОЯТЬ, УДЛИНН. РУКОЯТЬ, -НАВЕСН. ОБОРУД, ДЛЯ СЕВ. АМЕРИКИ

|$0

22J-943-3902

Arm Assembly

|$1

22J-943-3901

Arm Assembly

1

Arm

1

Arm

2

22K-70-21530

Bushing

2

01573-20206

Seat, Welded

2

22F-943-2A90

Seat, Welded

3

07145-00030

Seal, Dust

4

22K-70-21540

Seal, Dust

5

22J-70-25270

Pin

6

07020-00000

Fitting, Grease

7

04082-00110

Lock

8

20N-70-11280

Spacer, T=1.0mm

9

01010-81020

Bolt

10

01643-31032

Washer

11

22L-973-2331

Hose

11

22L-973-2330

Hose

12

22K-973-2611

Tube

12

02784-10422

Joint

12

02788-00422

Nut and Sleeve

13

22L-973-1252

Clamp

14

22L-973-1262

Clamp

15

01010-81070

Bolt

16

01643-31032

Washer

17

22F-973-2660

Union Assembly

18

02896-11012

O-ring

19

22F-62-32220

Plug

20

22F-973-2631

Bracket

21

01010-81025

Bolt

22

01643-31032

Washer

23

22F-973-2660

Union Assembly

24

02896-11012

O-ring

25

22F-62-32220

Plug

26

22F-973-2641

Bracket

27

01010-81025

Bolt

28

01643-31032

Washer

29

22J-943-2621

Tube

30

02896-11008

O-ring

31

22J-943-2631

Tube

32

02896-11008

O-ring

33

22J-943-3740

Clamp

33

20M-943-8140

Clamp

34

22J-943-3750

Clamp

34

20M-943-8151

Clamp

35

01010-80816

Bolt

36

01643-30823

Washer

37

01010-80820

Bolt

38

01643-30823

Washer
