Запчасти Komatsu PC18MR-3 РУКОЯТЬ, ВНУТР. ЧАСТИ, ГИДРОМОЛОТ (№-) РУКОЯТЬ, ДЛЯ MACHINE С ГИДРОМОЛОТОМ

|$0

22J-970-2710

Breaker Assembly

1

22J-971-2510

Cap

2

21S-970-2220

Bolt, Cap

3

21S-970-2230

Washer, Seal

4

22J-971-2520

Cover

5

21S-970-2250

Diaphragm

6

21S-970-2260

Shell

7

21S-970-2270

Ring, Back-up

8

21S-970-2280

O-ring

9

21S-970-2290

Bolt

10

22J-971-2530

Body, Valve

11

21S-970-2140

Plug

12

22J-971-2540

Bolt

13

22J-971-2550

Valve, Control

14

21S-970-2370

Plug

15

21S-970-2380

Spring

16

21S-970-2390

Ball, Steel

17

22J-971-2560

Tube, Inner

18

22J-971-2570

Piston

19

22J-971-2580

O-ring

20

21S-970-2450

Pin

21

22J-971-2590

Cylinder

22

20M-970-7470

Plug

23

22J-971-2610

Packing

24

22J-971-2620

Seal, Dust

25

22J-971-2630

End, Front

26

22J-971-2640

Washer

27

20M-970-7530

Nut

28

21S-950-2550

Nipple, Grease

29

20M-970-7550

Pin, Lock

30

20P-971-7460

Pin, Ring

31

22J-971-2650

Bushing, Chisel

32

22J-971-2660

Bushing, Chisel

33

22J-971-2670

O-ring
