Запчасти Komatsu PC18MR-2 ОСНОВН. КЛАПАН (КЛАПАН EPC И PPC ЛИНИЯ) (РЕГУЛЯТОР) ( НАВЕСН.ОБОРУД) ГИДРАВЛИКА

1

22J-60-25811

BRACKET

2

01010-81025

BOLT

3

01643-31032

WASHER

4

22J-60-25822

BRACKET

5

01010-80816

BOLT

6

01643-30823

WASHER

7

22F-60-21201

VALVE ASS'Y,(SEE FIG.H0120-07A0)

8

01010-81020

BOLT

9

01643-31032

WASHER

10

22J-60-25831

BRACKET

11

21W-62-43980

ELBOW

12

07000-12011

O-RING

13

02896-11008

O-RING

14

21S-62-31471

ELBOW

15

07000-12011

O-RING

16

02896-11009

O-RING

17

21W-62-43980

ELBOW

18

07000-12011

O-RING

19

02896-11008

O-RING

20

22J-62-26730

HOSE

21

207-62-82790

ELBOW

22

07000-12011

O-RING

23

02896-11008

O-RING

24

22J-62-26721

HOSE,GREEN, RED

24

21U-62-34730

BAND, GREEN

24

21U-62-34760

BAND, RED

25

22J-62-26730

HOSE

26

22J-60-25850

BRACKET

27

01010-80820

BOLT

28

01643-30823

WASHER

29

22J-60-25600

SOLENOID VALVE

30

01252-60550

BOLT

31

22J-60-25611

BRACKET

32

22L-62-29130

NIPPLE,WITH O-RING

33

02896-11008

O-RING

34

22J-62-26810

HOSE,GREEN

34

21U-62-34730

BAND, GREEN

35

22J-62-26810

HOSE,WHITE

35

21U-62-34770

BAND, WHITE

36

22J-62-26831

HOSE,BROWN, YELLOW

36

21U-62-34780

BAND, BROWN

36

21U-62-34710

BAND, YELLOW

37

22J-62-26841

HOSE,BLACK, YELLOW

37

21U-62-34720

BAND, BLACK

37

21U-62-34710

BAND, YELLOW

38

22J-62-26851

HOSE,BLACK

38

21U-62-34720

BAND, BLACK

39

22J-62-26851

HOSE,RED

39

21U-62-34760

BAND, RED

40

22J-62-26870

HOSE,WHITE, BLUE

40

21U-62-34770

BAND, WHITE

40

21U-62-34750

BAND, BLUE

41

22J-62-26881

HOSE,WHITE, WHITE

41

21U-62-34770

BAND, WHITE

42

22J-62-26910

HOSE,ORANGE

42

21U-62-34740

BAND, ORANGE

43

22J-62-26920

HOSE,BROWN

43

21U-62-34780

BAND, BROWN

44

22J-62-26930

HOSE,ORANGE, YELLOW

44

21U-62-34740

BAND, ORANGE

44

21U-62-34710

BAND, YELLOW

45

22J-62-26971

HOSE,GREEN, YELLOW

45

21U-62-34730

BAND, GREEN

45

21U-62-34710

BAND, YELLOW

46

22J-62-26950

HOSE,YELLOW

46

21U-62-34710

BAND, YELLOW

47

22J-62-26950

HOSE,BLUE

47

21U-62-34750

BAND, BLUE

48

22J-62-26971

HOSE,WHITE, RED

48

21U-62-34770

BAND, WHITE

48

21U-62-34760

BAND, RED

49

22J-62-26980

HOSE,RED, RED

49

21U-62-34760

BAND, RED

50

20P-62-72380

SHEET

51

08034-20823

BAND

52

04435-51210

CLIP

53

01010-81020

BOLT

54

01643-31032

WASHER

55

198-61-14180

CLIP

55

22M-977-1140

CLIP

56

01010-81025

BOLT

57

01643-31032

WASHER
