Запчасти Komatsu PC18MR-2 ГИДРОМОЛОТ РУКОЯТЬ (ГИДРОМОЛОТ ВНУТР. ЧАСТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

22J-970-2710

BREAKER ASS'Y

1

22J-971-2510

CAP

2

21S-970-2220

BOLT,CAP

3

21S-970-2230

WASHER,SEAL

4

22J-971-2520

COVER

5

21S-970-2250

DIAPHRAGM

6

21S-970-2260

SHELL

7

21S-970-2270

RING,BACK-UP

8

21S-970-2280

O-RING

9

21S-970-2290

BOLT

10

22J-971-2530

BODY,VALVE

11

21S-970-2140

PLUG

12

22J-971-2540

BOLT

13

22J-971-2550

VALVE,CONTROL

14

21S-970-2370

PLUG

15

21S-970-2380

SPRING

16

21S-970-2390

BALL,STEEL

17

22J-971-2560

TUBE,INNER

18

22J-971-2570

PISTON

19

22J-971-2580

O-RING

20

21S-970-2450

PIN

21

22J-971-2590

CYLINDER

22

20M-970-7470

PLUG

23

22J-971-2610

PACKING

24

22J-971-2620

SEAL,DUST

25

22J-971-2630

END,FRONT

26

22J-971-2640

WASHER

27

20M-970-7530

NUT

28

21S-950-2550

NIPPLE,GREASE

29

20M-970-7550

PIN,LOCK

30

20P-971-7460

PIN,RING

31

22J-971-2650

BUSHING,CHISEL

32

22J-971-2660

BUSHING,CHISEL

33

22J-971-2670

O-RING
