Запчасти Komatsu PC18MR-2 УДЛИНН. РУКОЯТЬ ( НАВЕСН.ОБОРУД) (КРОМЕ ЯПОН.) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

22J-943-2702

ARM ASS'Y,LONG

|$3

22J-943-2701

ARM ASS'Y,LONG

1

ARM,LONG

1

ARM,LONG

2

22J-70-25231

BUSHING

3

07145-00030

SEAL,DUST

4

22K-70-21540

SEAL,DUST

5

22J-70-25270

PIN

6

07020-00000

FITTING,GREASE

7

04082-00110

LOCK

8

20N-70-11280

SPACER, 1.0MM

9

01010-81020

BOLT

10

01643-31032

WASHER

11

22J-943-2621

TUBE

11

22J-943-2620

TUBE

12

22J-943-2631

TUBE

13

22J-943-1B80

CLAMP

14

22J-943-1B90

CLAMP

15

01010-80816

BOLT

16

01643-30823

WASHER

17

22L-973-2330

HOSE

18

22K-973-2611

TUBE

19

22L-973-1252

CLAMP

20

22L-973-1262

CLAMP

21

01010-81070

BOLT

22

01643-31032

WASHER

23

22F-973-2660

JOINT ASS'Y

24

02896-11012

O-RING

25

22F-973-2570

COUPLING

26

22F-973-2680

CAP

27

22F-973-2631

BRACKET,L.H.

28

01010-81025

BOLT

29

01643-31032

WASHER

30

22F-973-2660

JOINT ASS'Y

31

02896-11012

O-RING

32

22L-973-2750

COUPLING

33

22L-973-2760

CAP

34

22F-973-2641

BRACKET,R.H.

35

01010-81025

BOLT

36

01643-31032

WASHER
