Артикул
Название
Примечание
Количество
|1
702-16-04250
PILOT VALVE
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1670-01A0 AND Y1670-02A0.
1
BODY,VALVE
2
VALVE
3
702-16-51140
SHIM¤ 0.30MM
4
702-16-53420
SPRING
5
702-16-53140
RETAINER
6
702-16-54420
SPRING
7
702-16-53170
PISTON
8
702-16-71150
SEAL
9
702-16-71160
SEAT
10
702-16-73630
CASE
11
LEVER
12
SHAFT
13
PLATE
14
01010-80855
BOLT
15
01643-30823
WASHER
16
01010-80816
BOLT
17
702-16-54331
WASHER¤ 1.60MM
|17
702-16-54341
WASHER¤ 1.30MM
|17
702-16-54351
WASHER¤ 1.00MM
18
04025-00432
PIN,SPRING
19
702-16-54430
BUSHING
20
07000-12018
O-RING
21
702-16-73610
DAMPER ASS'Y
22
01023-10306
SCREW
23
702-16-73650
PIN
24
04022-04016
PIN,DOWEL
Выбрано товаров: 28
