Запчасти Komatsu PC180NLC-7-E0 ОСНОВН. КЛАПАН (8-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-58-16501

CONTROL VALVE

|1

723-58-16500

CONTROL VALVE

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1664-01A0 TO Y1664-31A0.

|1

723-20-94100

VALVE ASS'Y

1

BLOCK

2

SPOOL

3

723-20-94150

SPRING

4

723-20-94130

PLUG

5

07002-11623

O-RING

6

723-20-94140

FLANGE

7

07000-12011

O-RING

8

07000-11006

O-RING

9

07000-11007

O-RING

10

01252-60616

BOLT

11

BALL

12

PLUG

13

07000-11003

O-RING

14

07002-10823

O-RING

15

PLUG
