Запчасти Komatsu PC180NLC-7-E0 ОСНОВН. НАСОС (8/9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-3M-00030

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-09A0.

|1

708-1L-04760

VALVE ASS'Y,LS

1

708-2L-35311

SLEEVE

2

708-2L-24680

SEAL

3

708-2G-15460

SPOOL

4

708-2L-28540

PISTON

5

708-2L-35360

SLEEVE

6

708-2G-15420

SEAT

7

708-2L-35410

SPRING

8

708-2L-35341

SEAT

9

708-2L-35351

PLUG

10

07000-B1009

O-RING

11

07001-01009

RING,BACK-UP

12

01583-11408

NUT

13

07002-62434

O-RING
