МАРКИРОВКА
/

ТАБЛИЧКИ (PC8NLC)

Запчасти Komatsu PC180NLC-7-E0 ТАБЛИЧКИ (PC8NLC) МАРКИРОВКА

Схема запчастей Komatsu PC180NLC-7-E0 - ТАБЛИЧКИ (PC8NLC) МАРКИРОВКА
3
16
24
13
9
30
48
10
36
12
7
31
45
41
11
35
37
49
46
41
14
29
5
25
32
25
34
21
27
22
23
8
33
21
34
6
46
42
43
28
44
11
15
9
26
38
39
34
21
33
4
8
20
21
34
1
19
18
17
40
2
47
50

№

Артикул

Название

Примечание

Количество

|1

21K-00-K1295

PLATE KIT

|1

21K-00-K1294

PLATE KIT

|1

21K-00-K1293

PLATE KIT

|1

21K-00-K1292

PLATE KIT

1

09685-00002

PLATE¤ OPERATING,LOCK LEVER

2

20Y-00-K2220

PLATE,EMERGENCY EXIT

3

09690-M0063

PLATE¤ MARK,KOMATSU

4

09690-P0450

PLATE¤ MARK,KOMATSU

5

20E-00-K1150

PLATE¤ CAUTION,KEEP OFF SWING AREA

6

20E-00-K1140

PLATE¤ CAUTION,KEEP OFF WORKING AREA

7

09653-A0481

PLATE¤ SAFETY,HOT LIQUID

8

09657-A0881

PLATE¤ SAFETY,ADJUSTING TRACK TENSION

9

09659-A057B

PLATE¤ SAFETY,EXPLOSION HAZARD

10

09667-A0481

PLATE¤ SAFETY,ROTATION

11

09803-A0481

PLATE¤ SAFETY,WINDOW LOCK

12

09805-A0881

PLATE¤ SAFETY,KEEP AWAY FROM EDGE

13

09805-C0481

PLATE¤ SAFETY,HOOD

14

09808-A0881

PLATE¤ SAFETY,BATTERY CABLE

15

207-00-K1952

PLATE

|15

207-00-K1951

PLATE

16

09669-0000E

PLATE¤ CAUTION,FUEL

17

09963-A1640

TAG,DO NOT OPERATE

18

21K-00-K1530

PLATE¤ NAME

|18

21K-00-71450

PLATE¤ NAME

19

206-00-K1010

PLATE

20

20Y-00-31840

PLATE,SLING POSITION

21

09960-00801

MARK,SLING POSITION

22

20E-00-K1710

PLATE¤ CAUTION

23

20E-00-K1690

PLATE¤ CAUTION,ANTI-FREEZE

24

09669-0000C

PLATE¤ CAUTION,HYDRAULIC OIL

25

14X-98-35181

PLATE

26

22U-00-21511

PLATE,12V SOCKET

|26

207-00-K1770

PLATE,12V SOCKET

27

09696-40101

PLATE,EU DYNAMIC NOISE

28

09696-50068

PLATE¤ NOISE

29

09842-A0481

PLATE¤ CAUTION

30

09637-A0480

PLATE¤ INSTRUCTION,AIR CLEANER ELEMENT

|30

09637-A0640

PLATE¤ INSTRUCTION,AIR CLEANER ELEMENT

|30

20E-00-K1120

PLATE¤ INSTRUCTION,AIR CLEANER ELEMENT

31

09690-P1120

PLATE¤ MARK,KOMATSU

32

09690-P1120

PLATE¤ MARK,KOMATSU

33

21U-98-31160

PLATE¤ MARK,LOCATION OF CENTER OF GRAVITY

34

09960-00802

MARK

35

208-00-71261

PLATE,NOTICE

|35

208-00-71260

PLATE,NOTICE

36

20Y-00-41490

PLATE

37

20Y-00-41530

PLATE,ECOT 3

38

20Y-00-41341

PLATE,PRE-FILTER

|38

20Y-00-41340

PLATE,PRE-FILTER

39

20J-00-11271

PLATE¤ CAUTION

40

20Y-00-41461

PLATE,LOWER WINDOW

41

09642-A0480

PLATE

42

09601-02063

PLATE¤ NAME

|42

205-00-K1291

PLATE¤ NAME

43

04418-13060

SCREW

44

21K-00-K1211

PLATE¤ CAUTION

45

21K-00-71240

PLATE,LIFTING CAPACITY

46

21K-00-K1260

PLATE¤ MARK,PC180NLC

47

21K-00-71430

PLATE,OIL CHART

|48

20Y-00-K2980

DECAL KIT,ENGINE

48

6271-81-2980

PLATE,FUEL HIGH PRESSURE

49

600-181-1930

PLATE,AIR CLEANER

50

09845-00480

KOMTRAX WARNING DECAL

Выбрано товаров: 63
