Артикул
Название
Примечание
Количество
G1
20G-63-K2101
CYLINDER ASS'Y
|1
20G-63-K1110
CYLINDER ASS'Y
1
20G-63-K1540
CYLINDER
2
20G-63-K1570
ROD
3
20G-63-K1590
HEAD
4
20G-63-K1610
PISTON
5
707-40-14870
SPACER
6
01252-31250
BOLT
7
07179-13114
RING
8
707-52-90750
BUSHING
9
176-63-56170
SEAL
10
707-51-10030
PACKING
11
707-51-10630
RING
12
707-44-16180
RING
13
707-39-16820
RING,WEAR
14
707-44-16910
RING
15
07000-12080
O-RING
16
707-35-52920
RING,BACK-UP
17
07000-15155
O-RING
18
07001-05155
RING,BACK-UP
19
01010-82085
BOLT
20
707-88-75310
WASHER
21
07020-00000
FITTING,GREASE
22
707-76-90130
BUSHING
23
207-63-76170
BUSHING
24
205-70-62180
SEAL,DUST
25
702-21-08021
PILOT VALVE ASS'Y,(SEE FIG.Y1665-01A0)
26
07372-21055
BOLT
27
01643-51032
WASHER
28
07372-21060
BOLT
29
01643-51032
WASHER
30
07000-13030
O-RING
31
20G-60-K3210
FLANGE
32
01252-40635
BOLT
33
07000-02021
O-RING
34
07230-20210
UNION
35
07002-11423
O-RING
36
07040-11409
PLUG
37
07002-11423
O-RING
38
20G-62-K8130
ADAPTOR
39
07002-12034
O-RING
40
20G-62-K7080
TUBE
41
07000-13030
O-RING
42
07372-21035
BOLT
43
01643-51032
WASHER
44
20G-62-K7070
TUBE
45
07372-21060
BOLT
46
01643-51032
WASHER
47
07000-13030
O-RING
48
20G-60-K8010
BRACKET
49
07283-22236
CLIP
50
01599-01011
NUT
51
01643-31032
WASHER
52
01010-81240
BOLT
53
01643-31232
WASHER
Выбрано товаров: 55
