Запчасти Komatsu PC180NLC-6K КАБИНА (ОСНОВ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

21P-06-K2404

BASE ASS'Y

|1

21P-06-K2403

BASE ASS'Y

|1

21P-06-K2102

BASE ASS'Y

|1

21P-06-K2101

BASE ASS'Y

1

207-06-61510

BASE

2

20Y-06-24120

SWITCH ASS'Y,PUMP REDUNDANCY

3

01641-21223

WASHER

4

569-06-61960

RELAY

5

01435-00610

BOLT

6

21P-06-K2233

WIRING HARNESS

|6

21P-06-K2232

WIRING HARNESS

|6

21P-06-K2231

WIRING HARNESS

7

20Y-06-24130

SWITCH,SWING REDUNDANCY

8

283-06-16110

BOX,FUSE

9

195-Z11-2290

COVER,FUSE

10

283-06-16190

FUSE¤ 10A

|10

205-06-73180

FUSE¤ 15A

|10

22W-06-13160

FUSE¤ 20A

11

20Y-06-21460

CLIP

12

20Y-06-23960

CLIP

13

01023-10625

SCREW

14

20Y-979-2130

BOX ASS'Y

15

01435-01016

BOLT

16

20Y-979-2221

DUCT

17

01435-00610

BOLT

18

20Y-979-2231

DUCT

19

01435-00610

BOLT

20

20Y-979-2242

DUCT

21

01435-00610

BOLT

22

20Y-06-17220

RESISTOR

23

01435-00820

BOLT

24

203-06-56230

BUZZER ASS'Y

25

01435-00610

BOLT

26

7834-24-2004

CONTROLLER

|26

7834-24-2003

CONTROLLER

|26

7834-24-2001

CONTROLLER

27

01435-00880

BOLT

28

20Y-06-24410

CONTROLLER

29

01435-00630

BOLT

30

20Y-06-24220

SHEET

31

08051-00801

CLIP

32

20Y-06-23521

LOCK

33

01435-00820

BOLT

34

08017-30701

CONDUIT

35

01010-81020

BOLT

|35

01010-51020

BOLT

36

01643-31032

WASHER

37

08034-00519

BAND
