Артикул
Название
Примечание
Количество
|1
700-86-47000
VALVE ASS'Y,L.H.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6201 TO 6204.
|1
709-70-74402
VALVE ASS'Y,SUCTION AND SAFETY
1
709-70-71112
SLEEVE
2
SLEEVE
3
POPPET
4
SEAL
5
PISTON
6
709-70-71210
SPRING
7
PLUG
8
SEAL
9
709-70-71220
SPRING
10
07002-02434
O-RING
11
POPPET
12
SPRING
13
SCREW
14
O-RING
15
NUT
16
709-25-11390
O-RING
|17
709-70-55400
RELIEF VALVE ASS'Y,RELIEF
17
SLEEVE
18
709-70-51420
POPPET
19
709-70-51230
SPRING
20
700-20-51340
SCREW
21
07000-02011
O-RING
22
01582-11411
NUT
23
700-22-11410
O-RING
24
07002-02434
O-RING
25
700-20-51550
RING
26
VALVE
27
709-70-51210
SPRING
28
700-20-51540
RETAINER
Выбрано товаров: 32
