Артикул
Название
Примечание
Количество
|1
708-25-04032
PUMP ASS'Y,HYDRAULIC (HPV71+71)
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6101 TO 6171.
|1
708-25-04132
PUMP SUB ASS'Y,HYDRAULIC
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6111 TO 6115.
|1
708-25-00410
BLOCK ASS'Y,CYLINDER
1
708-25-13151
BLOCK,CYLINDER
2
708-25-13620
PLATE,VALVE
3
708-25-22722
SHAFT,REAR
4
708-25-13422
RETAINER,SHOE
5
708-25-13130
SPRING
6
708-25-13120
WASHER
7
708-25-13140
RING,SNAP
8
720-68-19610
PIN
9
708-25-13312
PISTON SUB ASS'Y
10
708-25-05061
SPACER KIT
|10
SPACER¤ 11.540MM
|10
SPACER¤ 11.560MM
|10
SPACER¤ 11.575MM
11
708-25-13441
RETAINER,BEARING
12
708-25-13470
SCREW
13
01643-30623
WASHER
14
708-25-14211
PISTON
15
708-25-14130
SPRING
16
708-25-24110
CAP
17
708-25-14150
CAP
18
07000-02065
O-RING
19
708-25-05050
SHIM KIT
|19
SHIM¤ 0.1MM
|19
SHIM¤ 0.1MM
|19
SHIM¤ 0.2MM
|19
SHIM¤ 0.5MM
20
01016-31035
BOLT
21
01643-31032
WASHER
Выбрано товаров: 33
