Запчасти Komatsu PC180NLC-5K ГИДР. НАСОС. (НАСОС SUB В СБОРЕ /) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|1

708-25-04032

PUMP ASS'Y,HYDRAULIC (HPV71+71)

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6101 TO 6171.

|1

708-25-04132

PUMP SUB ASS'Y,HYDRAULIC

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6111 TO 6115.

|1

708-25-00370

CASE ASS'Y,FRONT

1

CASE,FRONT

2

PLUG

3

07044-02412

PLUG

4

07002-02434

O-RING

5

720-68-19870

PLUG

6

07002-01223

O-RING

7

708-25-12340

O-RING

|8

708-25-00051

CRADLE ASS'Y,FRONT

|8

708-25-00520

CRADLE SUB ASS'Y,FRONT

8

CRADLE,FRONT

9

PLUG

10

708-25-23411

CAM,CAM

11

708-25-14121

SLIDER

12

708-25-12330

JOINT

13

07000-12015

O-RING

14

708-25-12350

BOLT

15

708-25-12360

PLATE

16

04020-00820

PIN,DOWEL

17

01010-30816

BOLT

18

708-25-12731

BEARING

19

708-25-05010

WASHER KIT

|19

WASHER¤ 2.0MM

|19

WASHER¤ 2.1MM

|19

WASHER¤ 2.2MM

20

708-25-12790

RING,SNAP

21

708-25-12812

HOUSING

22

708-25-05130

SHIM KIT

|22

SHIM¤ 0.1MM

|22

SHIM¤ 0.2MM

23

07000-02080

O-RING

24

708-25-52860

SEAL,OIL

25

708-25-12970

RING

26

01010-30820

BOLT

27

01643-30823

WASHER
