Запчасти Komatsu PC180NLC-5K ГИДР. НАСОС. (БЛОК) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|1

708-25-04032

PUMP ASS'Y,HYDRAULIC (HPV71+71)

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6101 TO 6171.

1

708-25-04132

PUMP SUB ASS'Y,HYDRAULIC

2

708-25-06131

SERVO VALVE ASS'Y,SERVO¤ FRONT

3

708-25-06231

SERVO VALVE ASS'Y,SERVO¤ REAR

4

04020-00616

PIN,DOWEL

5

708-25-19130

BOLT

6

01643-50823

WASHER

7

704-24-28240

PUMP ASS'Y

8

708-25-32730

COUPLING

9

708-25-22961

COLLAR

10

704-28-02710

O-RING

11

01010-31260

BOLT

12

01643-31232

WASHER

13

708-25-04311

RELIEF VALVE ASS'Y

14

708-25-29220

TEE

15

07040-11007

PLUG

16

07002-01023

O-RING

17

07002-02434

O-RING

18

708-25-29110

HOSE

19

07235-10422

ELBOW

20

07002-02034

O-RING

21

708-25-19120

FLANGE

22

720-68-15240

FILTER

23

07000-02021

O-RING

24

01010-30820

BOLT

25

01643-50823

WASHER

26

706-46-53260

PLUG

27

07002-01423

O-RING

28

708-25-29140

TUBE

29

706-46-53180

BOLT,JOINT

30

07000-02012

O-RING
